Sliding Door
Overview
In Sliding doors two or more frames slide horizontally on tracks to the left or the right. The doors are slightly raised above the track for smooth slide and also preventing dust from settling down in the track. Sliding doors are ideal for homes that require space-economy. Sliding doors are affordable option to bring more light into your home, as these cost effective doors can support large spans of glass and have a relatively slim vertical profile. �This allows you to maximise the amount of light that can enter your home, showcasing the space to best effect.
Technical Information
Single Glass
Glass: Single Glass
Profile System: SF2
Sizes represent a Design of 2Track / 2Sash in Frame
Height of Frame
2Sash French Door Max. Width: 900mm per Sash
| 2200 |  |
|
|
|
|
|
| 2000 | |
|
|
|
|
|
| 1800 | |
|
|
|
|
|
| 1000 | 1200 | 1400 | 1600 | 1800 | 2000 |
Outside Width of Frame
- Two Point Lock (Handle + Espag.)
Double Glass
Glass: Double GlassM
Profile System: SF2
Sizes represent a Design of 2Track / 2Sash in Frame
Height of Frame
2Sash French Door Max. Width: 900mm per Sash
| 2200 | |
|
|
|
|
|
| 2000 | |
|
|
|
|
|
| 1800 | |
|
|
|
|
|
| 1000 | 1200 | 1400 | 1600 | 1800 | 2000 |
Outside Width of Frame
- Two Point Lock (Handle + Espag. + Cylinder)
Gallery
